| Place of Origin: | China |
|---|---|
| Brand Name: | Ruiyuan |
| Certification: | UL/ISO9001/ISO14001/RoHS/Reach |
| Model Number: | 0.045mm |
| Minimum Order Quantity: | 5kg |
| Price: | Negotiation |
| Packaging Details: | Carton |
| Delivery Time: | 2-15 days |
| Payment Terms: | Negotiation |
| Supply Ability: | 10Ton/week |
| Product Name: | 45 AWG 0.045mm 2UEW155 Super Thin Magnet Winding Wire Enamel Solderable | Thermal Rating: | 155 |
|---|---|---|---|
| Insulation Material: | UEW | Diameter: | 0.045mm |
| Conductor Material: | Copper | Key Word: | 45 AWG 0.045mm 2UEW155 Super Thin Magnet Winding Wire Enamel Solderable |
| Highlight: | 2UEW155 Magnet Winding Wire,45 AWG Magnet Winding Wire,0.045mm Magnet Winding Wire |
||
45 AWG 0.045mm 2UEW155 Super Thin Magnet Winding Wire Enamel Solderable
In the medical field, the importance of high-quality materials cannot be overstated.
Ruiyuan's enameled copper wire is used in medical devices where precision and reliability are critical. From MRI machines to ultrasound equipment, our ultra-fine winding wire is an integral part of the operation of these precision instruments.
The temperature ratings of our wire (155 degrees, 180 degrees, 200 degrees, and 220 degrees) ensure that it can withstand the harsh environments common in medical applications. This durability not only improves the performance of medical equipment, but also contributes to patient safety and care.
| Test Items | Requirements | Test Data | ||
| 1st Sample | 2nd Sample | 3rd Sample | ||
| Appearance | Smooth & Clean | OK | OK | OK |
| Conductor Diameter | 0.045mm ±0.001mm | 0.0450 | 0.0450 | 0.0450 |
| Thickness of Insulation | ≥ 0.006 mm | 0.0090 | 0.0080 | 0.0090 |
| Overall Diameter | ≤ 0.056 mm | 0.0540 | 0.0530 | 0.0540 |
| DC Resistance | ≤ 11.339 Ω/m | 10.740 | 10.698 | 10.743 |
| Elongation | ≥ 11% | 22 | 20 | 21 |
| Breakdown Voltage | ≥350 V | 1764 | 1567 | 1452 |
| Pin Hole | ≤ 5(faults)/5m | 0 | 0 | 0 |
| Adherence | No cracks visible | OK | OK | OK |
| Cut-through | 200℃ 2min No breakdown | OK | OK | OK |
| Heat Shock | 175±5℃/30min No cracks | OK | OK | OK |
| Solderability | 390± 5℃ 2 Sec No slags | OK | OK | OK |
