| Place of Origin: | China |
|---|---|
| Brand Name: | Ruiyuan |
| Certification: | UL/ISO9001/ISO14001/RoHS/Reach |
| Model Number: | OCC |
| Minimum Order Quantity: | 1 kg |
| Price: | Negotiation |
| Packaging Details: | Carton |
| Delivery Time: | 2-15 days |
| Payment Terms: | Negotiation |
| Supply Ability: | 10/week |
| Product Name: | 0.025mm 6N/7N High-purity Super Fine Insulated/Bare OCC Copper Wire For Audio | Thermal Rating: | 155 |
|---|---|---|---|
| Insulation Material: | Enamel | Diameter: | 0.025mm |
| Conductor Material: | Copper | Key Word: | 0.025mm 6N/7N High-purity Super Fine Insulated/Bare OCC Copper Wire For Audio |
| Highlight: | 0.025mm OCC Copper Wire,High-purity OCC Copper Wire,6N/7N OCC Copper Wire |
||
0.025mm 6N/7N High-purity Super Fine Insulated/Bare OCC Copper Wire for Audio
At present, the entire industry is facing the problem that it is difficult to directly confirm single crystal copper. But we can increase the basis for judging single crystal copper through specific production equipment and processes. For example, copper materials produced by vacuum single crystal melting furnaces can largely ensure that they have a single crystal structure. Because this kind of equipment can provide specific conditions for the growth of single crystal copper, which is conducive to the formation of columnar crystals and the reduction of grain boundaries.
|
Name |
0.025mm 6N/7N High-purity Super Fine Insulated/Bare OCC Copper Wire for Audio |
|
Key word |
0.025mm 6N/7N High-purity Super Fine Insulated/Bare OCC Copper Wire for Audio |
|
Thermal rating |
155 |
| Item | Tech requirement | Test value | ||
| Overall dimention mm | Max.0.035 | 0.035 | 0.034 | 0.0345 |
| Conductor Diameter mm |
0.025±0.002 |
0.025 |
0.025 |
0.025 |
|
Conductor resistance Ω/m
|
Tested value |
35.1 |
35.1 |
35.1 |
| Pinhole (5m) pcs |
Max 5 |
0 |
0 |
0 |
| Elongation % |
Min 10 |
16.8 |
15.2 |
16 |
| Solderability |
Max 2 |
OK |
||
