| Place of Origin: | China |
|---|---|
| Brand Name: | Ruiyuan |
| Certification: | UL/ISO9001/ISO14001/RoHS/Reach |
| Model Number: | EIW |
| Minimum Order Quantity: | 10kg |
| Price: | Negotiation |
| Packaging Details: | Carton |
| Delivery Time: | 2-15 days |
| Payment Terms: | Negotiation |
| Supply Ability: | 10Ton/week |
| Product Name: | Insulated Rectangular Copper Wire 0.8mm X 2.0mm EIW Class 180 Flat Enameled Copper Wire | Thermal Rating: | 180 |
|---|---|---|---|
| Insulation Material: | EIW | Width: | 2.00 |
| Thickness: | 0.80 | Conductor Material: | Copper |
| Key Word: | Insulated Rectangular Copper Wire 0.8mm X 2.0mm EIW Class 180 Flat Enameled Copper Wire | ||
| Highlight: | insulated flat enameled copper wire,eiw flat enameled copper wire,0.8mm enameled flat copper wire |
||
Insulated Rectangular Copper Wire 0.8mm x 2.0mm EIW Class 180 Flat Enameled Copper Wire
Our commitment to meeting our customers' unique requirements allows us to provide customized solutions that drive the future of motor technology. Whether improving energy efficiency, increasing power output or achieving thermal stability, enamelled flat copper wire is the cornerstone of innovation and progress in the motor industry.
| Characteristics | Standard | Test Result | ||
| Appearance | Smooth Equality | Smooth Equality | ||
| Conductor Diameter | Width | 2.00 | ±0.030 | 1.974 |
| Thickness | 0.80 | ±0.030 | 0.798 | |
| Min.thickness of insulation | Width | 0.120 | 0.149 | |
| Thickness | 0.120 | 0.169 | ||
| Overall Diameter | Width | 2.20 | 2.123 | |
| Thickness | 1.00 | 0.967 | ||
| Pinhole | Max. 0 hole/m | 0 | ||
| Elongation | Min. 30 % | 40 | ||
| Flexibility and Adherence | No crack | No crack | ||
| Conductor Resistance (Ω/km at 20℃) | Max 11.79 | 11.51 | ||
| Breakdown Voltage | Min. 2.00kv | 7.50 | ||
| Heat shock | No Crack | No Crack | ||
| Conclusion | Pass | |||
