| Place of Origin: | China |
|---|---|
| Brand Name: | Ruiyuan |
| Certification: | UL/ISO9001/ISO14001/RoHS/Reach |
| Model Number: | OCC |
| Minimum Order Quantity: | 1 kg |
| Price: | Negotiation |
| Packaging Details: | Carton |
| Delivery Time: | 2-15 days |
| Payment Terms: | Negotiation |
| Supply Ability: | 10Ton/week |
| Product Name: | Custom 0.025-0.100 Occ Wire Ohno Continuous Casting 99.998% For Audio Products | Thermal Rating: | 155 |
|---|---|---|---|
| Insulation Material: | Bare Copper Wire | Diameter: | 0.08mm |
| Conductor Material: | Copper | Key Word: | Custom 0.025-0.100 Occ Wire Ohno Continuous Casting 99.998% For Audio Products |
| Highlight: | occ wire for audio products,0.025 occ wire,0.1 occ copper wire |
||
Custom 0.025-0.100 Occ Wire Ohno Continuous Casting 99.998% For Audio Products
Application:
1. High-end audio equipment: High-purity enamelled sterling silver wire is widely used in high-end impression and audio fields, providing real and lifelike sound effects in the music field.
2. Voice coil: This wire can be used in the manufacture of voice coil coils. The low resistance value and high conductivity greatly improve the stability and sound quality of the voice coil.
|
Name |
Custom 0.025-0.100 Occ Wire Ohno Continuous Casting 99.998% For Audio Products |
|
Key word |
Custom 0.025-0.100 Occ Wire Ohno Continuous Casting 99.998% For Audio Products |
|
Thermal rating |
155 |
|
Diameter |
0.5mm |
| Item | Unit | Requirement | Test result | ||
| Max. |
Min.
|
Mean.
|
|||
|
Single Over-all Diamerter |
[mm] | Max 0.56 |
0.52 |
0.52 |
0.52 |
|
Twisting ditection |
[mm] | Min 0.008 |
0.01 |
0.015 |
0.0125 |
|
Twisting distance |
[mm] | 0.500±1 |
0.500 |
0.490 |
0.495 |
|
Conductor resistance |
[Ω/m] |
—— |
0.107 |
0.107 |
0.107 |
|
Pinhole (6m) |
[个] | Max. 5 |
0 |
0 |
0 |
|
Single wire Elongation |
[%] | Min. 20 |
32.94 |
32.94 |
32.94 |
|
Conductor resistance |
[gf] | Min. 3688 |
3716 |
3716 |
3716 |
|
Solderability |
[s] | Max. 2 |
OK |
||
