| Product Name: | 0.015mm Enamele Copper Wire | Thickness: | 0.02-1.8mm |
|---|---|---|---|
| Width: | 0.155-7.5mm | Width To Thickess Ratio: | 1:1.5-1:25 |
| Color: | Nature/Black | Insulation: | UEW/AIW/EIW |
| Thermal Class: | 180-220 | Material: | Copper |
| Standard: | JIS/IEC/NEMA | ||
| Highlight: | rectangular magnet wire,square magnet wire |
||
THERMAL RATING 180-220 NATURE COLOR FLAT ENAMELED COPPER WIRE RECTANGULAR MAGNET WINDING WIRE
We offers a complete range of enameled, yarn-covered or taped rectangular copper wires.
Different types of enamel with very good mechanical strength and bonding properties
Very consistent quality and dimension tolerances in line with industry standards
Wide range of dimensions, yarns and insulation builds available
Very thin grades for wind turbine generators
Improved mechanical strength, high-performance yarns and impregnation varnishes
Very high resistance to corona discharges for inverter applications
High-temperature class (original Pyre-ML® enamel used) with high- breakdown voltage
Soft wire for easy winding
CERTIFICATES
ISO 9001-2000, ISO TS 16949, ISO 14001-2004,
UL Approved, RoHS Directive Met
Executive standards: IEC, JIS and NEMA.
FEATURES AND BENEFITS
The insualtion of flat wire could be bondable per the requirement of customers
Flat enameled copper wire with larger volume efficient(as the comparion table),will decrease volume of coils
The flat enameled copper wire has a low frict coefficient and good winding property
The flat enameled copper wire has a wide length/thickness ration from 1 to 25.
APPLICATION
Note book coil
Coils for printer
Transformer
Speaker
|
Parameter |
Class 130 |
Class 155 |
Class-180 |
Class-200 |
Class220 |
Class-240 |
|
Standards |
IEC60317-16 GB/T7095.7 |
60317-16 GB/T7095.3 |
60317-28 GB/T7095.4 |
MW 36 60317-29 BS6811 GB/T7095.6 |
MW 18 60317-18 GB/T7095.2 |
MW 20 60317-47 GB/T7095.5 |
|
Thermal Class |
130°C |
155°C |
180°C |
200°C |
120°C |
240°C |
|
Enamel Base Coat |
Polyester |
Modified Polyester |
Polyester-Imide |
Polyester-Imide |
Polyester-formal |
Polyimide |
|
Enamel Top Coat |
|
|
|
Polyester-Imide |
|
|
|
Range of insulation thickness |
IEC60317-0-2 G1,0.06-0.11mm G2,0.12-0.17mm |
|||||
|
Performance |
1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property
|
1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property 5.Higher thermal property |
1.High thermal resistance 2.Suitable for windings that are subjected to constantly high temperature and mechanical stress 3.Good chemical resistance1. |
1.Excellent thermal resistance 2.Suitable for windings that are subjected to constantly high temperature and mechanical stress 3.Good chemical resistance 4.Good resistance to refrigerant and freon1. |
1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property1. |
1.Excellent thermal resistance suitable for any electric equipment that are constantly exposed to high working temperature 2.Outstanding mechanical and chemical property 3.Good performance against radiation1. |
|
Application |
1.Dry and oil-immersed 2.Electrical equipment
|
1.Dry and oil-immersed 2.Electrical equipment |
1.Windings of high and low voltage DC/AC motor 2.Magnet coil 3.Dry and oil-immersed transformer1. |
1.Windings of high and low voltage DC/AC motor 2.Magnet coil 3.Dry and oil-immersed transformer 4.Automobile coil 5.Train coil1. |
1.Dry and oil-immersed transformer 2.Electrical equipment |
1.Windings with service temperature up to 220°C 2.Motor and generator for aviation and marine application 3.Nuclear industry 4.Windings requiring high reliability
|
|
Heat shock |
155°C |
175°C |
200°C |
220°C |
155°C |
