| Place of Origin: | China |
|---|---|
| Brand Name: | Rvyuan |
| Certification: | UL/ISO/SGS |
| Model Number: | 0.15*1.00mm |
| Minimum Order Quantity: | 20-100kg |
| Price: | Negotiation |
| Packaging Details: | Carton and pallet |
| Delivery Time: | within 5-10 working days |
| Payment Terms: | Negotiation |
| Supply Ability: | 200 Ton/Tons per Month |
| Product Name: | Self Bonding Flat Copper Wire | Thickness: | 0.04-1.8mm |
|---|---|---|---|
| Width: | 0.155-7.5mm | Width To Thickess Ratio: | 1:1.5-1:25 |
| Color: | Nature/Black | Insulation: | UEW/AIW/EIW |
| Thermal Class: | 155-220 | Rated Voltage: | 1.8KV |
| Highlight: | self bonding copper wire,enameled magnet wire |
||
SUPER THIN FLAT ENAMELED COPPER WIRE FOR TRANSFORMER
Customer has requested that to be more efficient in using space, high electricity and density in the developing stage of the high spec and quality coil. We, Unimac Japan have developed this product successfully by using the above the requirements. The property of our flat magnet wire outweigh the round wire which is from 0.07mm to 1.7mm in a cross section, and the flat wire's conductor was insulated accordingly. It will give you a wide-ranged of possibility on your products. In addition, it will contribute to the minimization of volume, weight reduction and enhance the electrical efficiency on our product.
|
SFT type |
|||||||
|
|
Fine flat wire |
Ultrafine flat wire |
|||||
|
Insulating resin |
Modified polyester |
Polyamideimide |
Polyamideimide |
||||
|
Index |
SFT-FH |
SFT-BH-N1 |
SFT-AIWU |
SFT-BA-NV |
SFT-BA-NV |
||
|
Size(mm) |
0.14×2.0 |
0.70×2.0 |
0.10×2.0 |
0.70×3.0 |
0.02×0.3 |
0.10×0.6 |
|
|
Conductor |
Thickness |
0.140 |
0.700 |
0.100 |
0.700 |
0.020 |
0.100 |
|
Width |
2.00 |
2.00 |
2.00 |
3.00 |
0.30 |
0.60 |
|
|
Insulation Film(mm) |
0.015 |
0.017/0.004 |
0.015 |
0.020/0.002 |
0.005/0.002 |
0.005/0.002 |
|
|
Outside(mm) |
Thickness |
0.170 |
0.742 |
0.130 |
0.744 |
0.034 |
0.114 |
|
Width |
2.03 |
2.04 |
2.03 |
3.04 |
0.32 |
0.62 |
|
|
B.D.V(KV) |
1.5 |
3.0 |
3.0 |
3.5 |
0.7 |
11.5 |
|
|
Conductor resistance (ohm/km |
63.90 |
14.00 |
92.30 |
8.50 |
3200 |
310 |
|
|
Elongation(%) |
35.0 |
25.0 |
35.0 |
35.0 |
25.0 |
|
|
|
Solubility |
430℃×3sec |
430℃×3sec |
|
||||
|
Stickness(N) |
5.0 |
8.0 |
0.6 |
||||
